Deiiang Purifier" Air Shower Room Function

Air shower room is used in various dust-free workshops and non-dust-free workshops and step cleanliness workshops such as microelectronics, optoelectronics, semiconductors, medicine, food, chemicals, aviation, automobiles, printing, and laboratories. It is used to remove dust particles larger than 0.3 microns from various parts of the human body when entering a high-cleanliness room from a low-cleanliness room, so as to avoid contamination after entering the clean room. At the same time, it also plays the role of air flow buffering, because in the process of opening the door, there is air flow, and the air shower room stops the air flow inside the air shower room very well, which well avoids air pollution caused by air flow.

Deiiang Purifier" air shower room features

Fully automatic control, electronic interlocking, double door lock during showering, infrared induction automatic showering. Stainless steel semi-glass door automatic door closer, transparent window, inner lower plate is made of stainless steel; software test controller, LED display and setting shower time, adjustable range 0~99 seconds, circular involute air duct inside, high wind speed, low noise.

• Humanized control panel design, clear indicator light indication, give clear air shower process indication. Soft key touch time relay;

• High cleanliness, high wind speed: adopt primary and high efficiency filter two-stage filtration system, low resistance high efficiency filter without partition, filtration efficiency: 99.99%, ensure purification level. Equipped with all stainless steel multi-angle adjustable nozzle, double volute outer rotor large air volume low noise fan, the wind speed at the nozzle outlet is as high as 25m/s or more, and the wind speed blowing on the person is more than 18m/s.

• Modular structure, the air shower room box adopts modular design scheme, which can be assembled into various lengths of air shower sizes according to actual needs. An air shower room consists of one or more air shower units. For large-volume air shower equipment, it can be disassembled into multiple modules, making production, transportation and installation particularly convenient and fast;

• High performance, high sealing: imported electronic components are used, the operation performance is stable and reliable, advanced noise reduction and silencing device system and EVA sealing materials are used, and the sealing performance is high.

Deiiang Purifier" air shower room structure configuration

• Automatic control, the single-person single-blow air shower room system adopts PLC intelligent control means, and the LED display screen on the control panel can correctly display the running status of the air shower, the interlocking status of the double doors, the progress of the air shower cycle and the delayed door opening status. It is also equipped with a photoelectric sensor, a one-way channel air shower room, and when entering from a non-clean area, the infrared ray senses the person and the shower starts after the door is closed. After the shower, the door is locked and the person can only leave the air shower room from the door;

• The single-person single-blow air shower room mainboard soft key touch time relay, LED display and setting of the shower time, the range is adjustable from 10-99s, and the shower time can be adjusted according to the difference in the external environment of the air shower room;

• Modular structure, the single-person single-blow air shower room box adopts a modular design scheme;

• High performance, high sealing, using imported electronic components, stable and reliable operating performance, advanced noise reduction and silencing device system and EVA sealing materials, high sealing performance.

Deiiang Purifier" air shower room usage requirements

The air shower room is a necessary passage for people to enter the clean room. It can reduce the pollution problems caused by entering and exiting the clean room, and reduce the large amount of dust particles caused by the entry and exit of people and goods. Installing a fully functional "airlock" at the entrance of the clean room can reduce the number of air pollution particles. When people and goods pass through the air shower room, the polluted particles are ejected by highly clean air that has been filtered through high efficiency. The high wind speed of more than 25m/s ensures that the effective injection and drifting particles are basically filtered out through the primary and high efficiency two-stage filters. In order to maintain the safe use of air showers and maintain the cleanliness of the clean room environment

1. When entering the clean room, you should take off your outer clothes in the outer dressing room, and remove your watches, mobile phones, accessories and other items.

2. When entering the inner dressing room, wear clean clothes, hats, masks and gloves.

3. After opening the stainless steel air shower door and entering the air shower room, the air shower door will automatically close the outer door immediately, infrared sensing, and the air shower will automatically start, blowing for 15 seconds.

Deiiang Purifier Air shower room maintenance method

• Pre-filter: The pre-filter is located below the device. Please remove the circulating air return port to easily pull out the pre-filter. The blockage of the pre-filter varies depending on the frequency of use and cleanliness. Please observe the blockage time in the initial use, and then clean it regularly by compressed air, water washing, vacuum cleaning, etc. It is necessary to clean it 2 to 3 times a month according to normal use.

• Main filter: This filter is located after the AIR NOZZLE. Its renewal period can be determined by the wind speed value detected by the anemometer (the wind value is halved) or the pressure difference measured by the pressure difference meter (the pressure difference value is doubled). The inspection cycle is about two to four times a year.

• Because the internal circulation return air part of the equipment is located below the machine, there will be large pollutants accumulated in the corners on the bottom plate, so please clean it with a vacuum cleaner at least once a week. Please confirm whether the rotation direction of the blower is correct. If the fan is found to be rotating in the opposite direction (wind speed is obviously insufficient), please swap any two phases of the three-phase power supply to ensure that it rotates in the positive direction.

Deiiang Purifier air shower room troubleshooting

• When the air shower room is used for a period of time, if the wind speed is very low, you should immediately check whether the filter of the air shower room has too much dust, and replace it with a new filter. It is usually necessary to replace it once every 1-6 months, and the high-efficiency filter is usually replaced once every 6-12 months.

• If the air shower room cannot automatically sense the shower, check the light sensing system in the lower right corner of the box in the air shower room to see if the light sensing device is correctly installed.

• If the emergency stop button is red, it means that the air shower room will not blow. You only need to press the emergency stop button again to work normally.

• When the air shower room does not work, first check whether the emergency switch of the outer box of the disadvantageous shower door is blocked. If it is blocked, press it lightly with your hand, turn it to the right and let it go.

• If the air shower room fan is reversed or the wind speed of the air shower room is very low, it is necessary to check whether the 380V three-phase four-wire line is connected in reverse. If the line source of the air shower room is reversed, the air shower room fan will not work or the wind speed of the reverse air shower room will decrease, and the circuit board of the entire air shower room will be burned in severe cases.
